Quam PS6L/QC10 2 Gang Selector & Attenuator 25/70/100V Stainless

Quam's PS6L/QC10 solves two problems in one convenient dual gang solution. The PS6L is a 6-position program selector switch that assigns the output of a 25, 70.7, or 100V amplifier to one or more loudspeakers up to a 20 watt maximum load. The QC10 is a UL-approved continuous rotary 10-step audio level attenuator for use with 25 or 70.7V distributed audio systems. It will attenuate the level of any number of loudspeakers up to a 20 watt maximum load. Made in Chicago, USA.

QC10 Specifications:
Power rating: 20 watts continuous
Attenuation: Position 10 full signal; position 9-3, -3 dB per step; position 2-1, -6 dB per step; position 0, -36 dB
Insertion loss: 1.0 dB
Mounting: Single gang electrical box, 2-1/8" depth
Audio connection: 7" long color-coded tinned wires, pre-cut.
