Description
This is a special order item. Once an order has been placed we will order in this product for you after payment has been received. Order will be held until all items are ready to ship.
The SYSTEM 6VPS is a complete, vandal resistant loudspeaker system consisting of a double re-entrant horn, compression type loudspeaker and integrated 16W-25/70V transformer mounted on a - square, stud mount, vandal resistant, stainless steel baffle with a - square, stainless steel, vandal resistant, surface mount enclosure with four (4) 8-32 threaded inserts and a single 1/2" conduit entrance. Three (3) interwoven, steel security screens are mounted between the faceplate and loudspeaker. Tamper resistant, 8-32 x 1" 'pin-in-torx' hardware included. White powder coat finish.
Specifications
System Components
| Average Sensitivity | 110 dB SPL, 1W/ 1M |
| Loudspeaker Power Rating | 16W RMS, EIA 426A Standard |
| Calculated Output | 121 dB SPL, 5W/ 1M |
| Magnet Type & Weight | BeFe Ceramic, 10 oz. Nominal |
| Frequency Response | 350Hz - 10kHz EIA 426A Standard |
| Nominal Coverage Angle | 90° Included Angle, -6 dB / 2 kHz, Half space |
| Audio Connection | 7” Color-Coded Pigtails, Pre-Cut |
| Loudspeaker | H16 |
| Transformer | Integral to unit 25/70V 16W-5 tap Color Coded Leads (16W, 8W, 4W, 2W, 1W) |
| Baffle | |
| Enclosure |
