Kenwood KAC-M3001 Marine Digital Amplifier - 300W 2-Channel Waterproof Stereo Audio System for Boats & Outdoor Adventures

Features:

• CEA-2006 Compliant
• Class D
• 2 Ohms Load Capability
• Speaker Level Input
• Signal Sensing Turn-on
• Power MOS-FET Switching Power Supply
• Extruded Aluminum Heat Sink Design
• RMS POWER Output 4Ω: 200W x 1
• RMS POWER Output 2Ω: 300W x 1
• Singal Sensing Turn-on
• Conformal Coating *1

Specifications:

• Amplifier Type: Class D
• CEA-2006 Primary Ratings:
  • Power Output: 200 Watts RMS x 1 at 4 Ohms and ≤1%THD+N
  • Signal-to-Noise Ratio: 78dBA (Reference: 1Watt into 4Ohms)
• Maximum Power Output: 600W
• Signal to Noise Ratio: 97dB (Reference: Rated Power into 4Ohms at 14.4V)
• Frequency Response: 20 Hz-200Hz (+0dB, -3dB)
• Input Impedance: 10k ohm
• Speaker Impedance: 4Ω (2Ω to 8Ω allowable)
• Bridged connection:
• Audio Section:
  • Low-Pass Filter: Built in Variable Low-Pass Filter (50Hz-200Hz, -24dB/oct)
  • High-Pass Filter: -
  • Filter Selector: -
  • RCA Input Sensitivity: 0.2 V - 5.0 V
  • Speaker Level Input Sensitivity: 4.0 V - 12.0 V
• Terminals:

  • Battery & Ground: Screw Type Terminal Block (Ni) (M4)
  • Speaker Output: MOLEX Connector with AWG16 200mm Wire
  • Line In: RCA (Ni)
• Operating Voltage: 14.4V•_ö11-16V allowable•_ä
• Current Consumption: 20A
• Others: Triangle Indicator
