Eminence KL3010CX 8 Ohm 10-Inch 450W Coaxial Woofer Speaker - Perfect for PA Systems, Live Sound & DJ Equipment
$147.95
$269
-45% OFF
Free shipping on all orders over $50
7-15 days international
11 people viewing this product right now!
30-day free returns
Secure checkout
63062328
Guranteed safe checkout
Description
10" High power subwoofer recommended for vented and horn loaded enclosures.
| Specification | |
| Nominal Basket Diameter | 10", 254 mm |
| Nominal Impedance* | 8 Ω |
| Power Rating* | |
| Program Power | 800 W |
| Watts | 400 W |
| Resonance | 55 Hz |
| Usable Frequency Range | 50 Hz - 3.7 kHz |
| Sensitivity* | 92 dB |
| Magnet Weight | 11 oz. |
| Gap Height | 0.365", 9.27 mm |
| Voice Coil Diameter | 3", 76 mm |
| Thiele & Small Parameters | |
| Resonant Frequency (fs) | 52 Hz |
| DC Resistance (Re) | 5.71 Ω |
| Coil Inductance (Le) | 0.62m H |
| Mechanical Q (Qms) | 5.87 |
| Electromagnetic Q (Qes) | 0.3 |
| Total Q (Qts) | 0.28 |
| Compliance Equivalent Volume (Vas) | 41.41 liters / 1.46 cu.ft. |
| Peak Diaphragm Displacement Volume (Vd) | 248 cc |
| Mechanical Compliance of Suspension (Cms) | 0.21 mm/N |
| BL Product (BL) | 16.8 T-M |
| Diaphragm Mass Inc. Airload (MMs) | 45 grams |
| Efficiency Bandwidth Product (EBP) | 175 |
| Maximum Linear Excursion (Xmax) | 6.58 mm |
| Surface Area of Cone (Sd) | 376.9 cm2 |
| Maximum Mechanical Limit (Xlim) | 17.84 mm |
| Mounting Information | |
| Recommended Enclosure Volume | |
| Sealed | N/a |
| Vented | Acceptable |
| Driver Volume Displaced | 0.037 cu.ft. / 1.06 liters |
| Overall Diameter | 10.25", 260.35 mm |
| Baffle Hole Diameter | 9.12", 231.65 mm |
| Front Sealing Gasket | Yes |
| Rear Sealing Gasket | Yes |
| Mounting Holes Diameter | 0.29", 7.366mm |
| Mounting Holes B.C.D. | 9.73", 247.14mm |
| Depth | 4.5625", 115.887 mm |
| Net Weight | 6.8 lbs, 3.08 kg |
| Shipping Weight | 8.6 lbs, 3.9 kgs |
| Materials of Construction | |
| Coil Construction | Copper voice coil |
| Coil Former | Fiberglass former |
| Magnet Composition | Neodymium magnet |
| Core Details | Tapered coax |
| Basket Materials | Die-cast aluminum basket |
| Cone Composition | Treated paper cone |
| Cone Edge Composition | Sealed cloth edge |
| Dust Cap Composition | Zurette dust cap |
