Diamond Audio MICRO84U 500W RMS 4-Channel Class D Car Amplifier - Powerful Sound System for Cars, Trucks & SUVs | Perfect for Upgrading Vehicle Audio & Enhancing Music Experience

Features:

• Diamond Audio Micro Series Class D 2 ohms Stable 4-Channel Amplifier
• RMS Power Rating:
• 4 ohms: 80 watts x 4 channel
• 2 ohms: 150 watts x 4 channel
• Bridged, 4 ohms: 300 watts x 2 channel
• Total power output: 600 watts
• Pulse Width Modulated MOSFET power supply
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Input sensitivity:
• Low level: 200mV - 10 volts
• Frequency Response: 10 - 30000 Hz
• Total Harmonic Distortion (THD): 0.5%
• Signal to Noise Ratio: -85 dB
• Variable high-pass filter: 40 - 400 Hz, 24 dB/octave
• Variable low-pass filter: 40 - 400 Hz, 24 dB/octave
• Fuse Rating: 40
• 8 AWG gauge power and ground wiring is recommended for installation.
• Dimensions: 4.06" W x 9.0" L x 1.52" H
